Product Name: EP Conveyor Belt
Fabric specs: EP80~EP630
Width(mm): 300-2400

Description:
EP Polyester Conveyor Belt, is woven by polyester in wrap and polyamide in weft. The EP Conveyor Belts have the characteristics of low elongation in wrap and good though ability in weft, good water proof, good wet strength, no mould suitable for medium long distance and heavy load transportation of material. Because of the high initial modulus of polyester, the belts can choose a relative low safety factor.



Polyester Fabric(EP) Conveyor Belt
Grade		EP100	EP125	EP150	EP200	EP250	EP300	EP350	EP400	EP500
Item
Min.Tensile Strength Working Tension Rating(Vulcanized)Approx,Gauge per Ply with skim coat.	Kg/cm-ply	100	125	150	200	250	300	350	400	500
	Kg/cm-ply	10.0	12.5	15.0	20.0	25.0	30.0	35.0	40.0	50.0
	mm	0.90	1.05	1.15	1.35	1.45	1.65	1.75	2.35	2.95

Features:
With the advantages of thin belt with light weight, high tensile strength, fatigue and wear resistance, erosion resistance of water/steam/chemical, good impact
resistance, excellent groove formation ability, low elongation, good stability ever heated and long service life, it's the developing trend of fabric conveyor belt. It
is mainly used in harsh condition of long distance, heavy-load, high-chemical corrosive etc, it is especially suitable for transporting in moist environment.

Structure:
It uses polyester canvas as carcass, its structure is the same as General-used Conveyor Belt.

Standards:
GB/T7984-2001, DIN22102, BS490, AS1332, RMA, JISK6322, SABS1173 etc.

Types:
Besides General-used EP Belt, there are Fire-retardant type, Cold-resistant type, Wear-resistant type, Heat-resistant type, Acid and alkaline resistant type, Oil -resistant type, Antistatic electricity type, High-grade type and etc.
